Build Your Own System Resource Monitor Using Python: A Step-by-Step Guide

Monitoring system resources like CPU usage, memory consumption, and disk activity is essential for optimizing performance and troubleshooting issues. Python, with its rich ecosystem of libraries, makes it easy to build a custom system resource monitor. In this guide, we’ll walk through the steps to create a simple yet effective resource monitor using Python.

Prerequisites

Before diving into the code, ensure you have the following:

Python installed on your system (preferably Python 3.x).

Basic knowledge of Python programming.

The psutil library, which is a powerful tool for retrieving system information.

You can install psutil using pip:

pip install psutil

Step 1: Import Required Libraries

Start by importing the necessary libraries. We’ll use psutil to fetch system data and time to create a loop for continuous monitoring.

import psutil
import time

Step 2: Define the Monitoring Function

Create a function to display system resource usage. This function will retrieve and print details about CPU, memory, and disk usage.

def monitor_system_resources():
    while True:
        # Fetch CPU usage
        cpu_usage = psutil.cpu_percent(interval=1)

        # Fetch memory usage
        memory_info = psutil.virtual_memory()
        memory_usage = memory_info.percent

        # Fetch disk usage
        disk_info = psutil.disk_usage('/')
        disk_usage = disk_info.percent

        # Print the results
        print(f"CPU Usage: {cpu_usage}%")
        print(f"Memory Usage: {memory_usage}%")
        print(f"Disk Usage: {disk_usage}%")
        print("-" * 30)

        # Wait for a few seconds before the next update
        time.sleep(5)

Step 3: Run the Monitor

Call the monitor_system_resources function to start monitoring. This will continuously display the resource usage in the terminal.

if __name__ == "__main__":
    monitor_system_resources()

Step 4: Customize and Enhance

The basic monitor is functional, but you can enhance it further:

Add Network Usage: Use psutil.net_io_counters() to monitor network activity.

Log Data: Save the resource usage data to a file for later analysis.

Create a GUI: Use libraries like tkinter or PyQt to build a graphical interface.

Set Alerts: Notify the user when resource usage exceeds a certain threshold.

Example Output

When you run the script, you’ll see output similar to this:

CPU Usage: 25.5%
Memory Usage: 45.3%
Disk Usage: 60.1%
------------------------------
CPU Usage: 30.1%
Memory Usage: 46.7%
Disk Usage: 60.2%
------------------------------

Conclusion

Building a system resource monitor in Python is a straightforward task, thanks to the psutil library. This tool can be a valuable addition to your development or system administration toolkit. By customizing and expanding the script, you can tailor it to meet your specific needs.

Happy coding!
